Modelo |
PRIME A520M-A II CSM |
Procesador |
AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series |
Socket |
AM4 |
Chipset |
AMD A520 |
Memoria RAM |
4 x DIMM, Max. 128GB, DDR4 4800(OC)/ 4600(OC)/ 4466(OC)/ 4400(OC)/ 4266(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3333(OC)/ 3200/ 3000/ 2800/ 2666/ 2400/ 2133 MHz, Un-buffered |
Puertos de expansión |
- 1 x PCIe 3.0 x16 (x16 mode)
- 1 x PCIe 3.0 x16 slot (supports x16 mode)
- 2 x PCIe 3.0 x1 slots
- 1 x M.2 (Key M), tipo 2242/2260/2280 (SATA y PCIe 3.0 x4)
- 4 x Sata 6GB/s
- Soporte RAID 0, 1, 10
|
Conexiones |
- 4 x USB 3.2 Gen 1
- 2 x USB 2.0
- 1 x DisplayPort
- 1 x HDMI
- 1 x D-Sub
- 1 x Puerto LAN (RJ-45) Realtek 1Gb
- 3 x Audio jacks
- 1 x Puerto combo teclado / mouse PS/2
|
WiFi / Bluetooth |
No posee |
LAN |
Realtek 1Gb |
Audio |
Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC |
CPU Ideal |
Ryzen 9 PRO 3900 |
Factor forma |
microATX 24.4cm x 24.4cm |
Cantidad por caja |
10 unidades |
